Model： Swing type
Type：Cup/Box Filling Machine
Order Hotline：0760-22122022
This series of machines from automatic cup, filling and sealing are automatic, optional photoelectric device, ensure the sealing patterns on it;
There are many types of specifications, suitable for different shapes and capacity of packaging containers;
Can be based on user needs, increase calcium tablets, pulp and other solid material filling function, and can be equipped with colored printing date;
This machine adopts stainless steel external structure;
According to customer requirements can choose imported components, programmable control.
Suitable for filling and sealing of containers such as plastic cups and containers. If frozen, ice cream, jam etc.;
Suitable for filling and sealing liquid filled containers such as plastic cups. Such as: yogurt, drinks, mineral water, etc.;
Type: turntable type
Gas source: 6-8kg/ square centimeter
Power supply: 50Hz 220V380V
Power: 1.5KW
Heat sealing times: 1
Heat sealing temperature: room temperature -250
Mold number: 7
Working speed: 600-1200 times / HR
Suitable for heat sealing film: plastic composite film, the film thickness is greater than 0.05mm
Cutting edge method: tooth cutter
Packaging container: plastic cup with heat sealing, plastic box
The next cup way: automatic
Filling volume: 30-150ml (adjustable)
Outline dimension: 990 * 925 * 1580mm
This machine is for the guests of the different needs, you can remove the filling function, changing the mold, can become: maltose sealing machine, the bean curd box sealing machine, jelly and sealing machine, yogurt and sealing machine, rice wine and sealing machine, sealing machine for noodles, cup sealing machine, juice and sealing machine, green bean and sealing machine, tea capper, potato chips and sealing machine, eight treasure porridge sealing machine and so on.
